5A 10A JK Smart 4S-24S BMS Active Balance Lifepo4 Battery Supercapacitor Equalizer Bluetooth Balancer Protection Board

Specification

Real-time, active, energy transfer equalization
after the balance inter-cell pressure difference ≤ 3mV
Support 4S to 24S battery packs.
Single-cell voltage collection range: 1V ~ 5V, accuracy: ± 3mV.
Support all pool types such as Li-ion, Lipo, Lifepo4, LTO, supercapacitors and other batteries.
The balance current:0.1~1A/2A/5A/10A, independent of the cell voltage difference.
Support balanced cascading to apply to more than 24S of battery packs, in theory, can be cascaded indefinitely; for example, 28S , 32S , 36S , 40S ...
Support Bluetooth communication, equipped with mobile APP, real-time view of battery status.
Equilibrium line resistance detection and abnormal contact failure are found in advance.
Power supply range: 40V~ 100V.
Low voltage shutdown function to prevent battery damage.
size :157*98.2*18.7 (1A/2A).the 5A/10A bigger size.
Super self-protection function, any equalization of the equalization line will not burn the equalizer.
